High-frequency RFID Chip 13.56MHz DC611 RFID chip ISO/IEC 14443-a
| Categories | RFID Reader Chips |
|---|---|
| Brand | DC-NFC Tag Manufacturer |
| Model | DC611 chip |
| category | DC611 chip |
| size | 2*2mm |
| standard | 14443A |
| chip | Read-write |
| frequency | 13.56MHZ |
| Type | HF |
| FOB port | Shenzhen |
| Terms of Payment | T/T |
| Update Time | May 04,2025 |
Detail Information
QFN16 DC611 chip
Description
High Quality
QFN16 DC611 chip
●Application industry:
Attendance and sign-in, access control, portable handheld devices
●Characteristic：
DC611, QFN16 DC611 chip
QFN16 DC611 chip
Specification
|
Features
|
Contactless transmission of data and supply energy
|
||
|
Operating frequency
|
13.56 MHz
|
||
|
Data transfer
|
106 kbit/s
|
||
|
Supports ISO/IEC 14443 TypeA reader/writer mode Supports ISO/IEC 14443 TypeB reader/writer mode Reader/writer mode supports M1 encryption ISO14443 TYPEA supports communication speeds of 106kbps, 212kbps, 424kbps Supports I2C interface, fast mode up to 400Kbps, and high-speed mode up to 3.4Mbps Host interface independent power supply 64Byte transmit receive buffer FIFO Flexible and configurable interrupt output mode |
|||
|
Two low-power modes -Soft Power Down Mode -Deep Power Down mode (typical value of 50nA at room temperature) programmable timer Built in oscillation circuit and external 27.12MHz crystal Wide voltage working range 2.5V~3.6V The RF transmission driver is powered by an independent power supply, with a maximum voltage of 5.5V Built in CRC coprocessor Programmable I/O pins Built in high-precision SAR ADC Built in high-sensitivity field detection circuit Built in low-power RC oscillator Support multiple LPCD detection modes |
|||
QFN16 DC611 chip
Applications
QFN16 DC611 chip
FAQ
How can I get the QFN16 DC611 chip Description Small price?
Please Send your inquiry Details or add our online tool then we can provide you with a quotation for the first time.
Can you offer free samples?
Yes, usually we can offer you free samples
A: For stock samples, we can send you free samples for your test, you pay for the shipping cost.
B: For customized samples, we will charge the reasonable production cost and try to refund you after order confirmed
What is your lead time?
Usually, our lead time is 1-7 days for samples and 7-20 days for mass production.
What's your payment method?
Our payment method are T/T, Ali Trade Assurance for mass production order; Paypal.
How can I Choose the chip?
Check above chips lists or just email with us of the application, we will give the best suggestions.
